BARISTA T
A professional machine for commercial spaces that meets the demand for more sustainable, energy-efficient, easy-to-use and durable products.
Reinventing Improvement
In the 1960s, the creation of the E‑61 group brought innovation to the world of espresso. It was an immediate success and became one of the most widely used systems in the history of espresso. Today, many manufacturers still use the E‑61 or similar systems based on the same principle. However, as the market, professionals, needs, and the world continue to evolve, we have the responsibility to offer new and improved technologies—reinventing ourselves without ever compromising coffee quality.
Sustainable engineering
We work continuously to differentiate and evolve our machines. The Barista T reinvents tradition by being built on sustainable engineering and offering greater energy efficiency. T Technology combines multi‑group technology with independent thermoblocks for coffee and a separate steam boiler.
Healthy, fast and reliable
Using only stainless steel and 99% pure copper in the water circuit ensures purer, healthier beverages. Thanks to its rapid heat‑up time, it allows you to serve delicious, professional‑quality espresso in just one minute.
Highlights
Thermoblock
Professional thermoblocks with dynamic preheating system
Pid Control
Thermal stability of +/-0.5°C with PID controller
Rotary pump
Rotary pump with dimensioning, programmable pre-infusion and extraction timer
High-definition touchscreen
High-definition touch screen for easy adjustment of machine parameters
MULTIGROUPS
Multi-group system with independent steam boiler in stainless steel
High quality
High-quality materials, accessories and components in stainless steel
Filter holder
Portafilter (Ø58mm), filters and showers in stainless steel
Design
Modern and industrial design
| Sheet | ||||||
|---|---|---|---|---|---|---|
 |
 |
 |
||||
| Barista T Pro | Barista T | Barista T One | ||||
| 2 groups | 3 groups | 2 groups | 3 groups | 2 groups | 3 groups | |
| Pump | Rotary | Rotary | Rotary | Rotary | Rotary | Rotary |
| 4.2" LCD screen | ||||||
| Digital Multifunction Display | 2 per group | 2 per group | 2 per group | 2 per group | 2 per group | 2 per group |
| PID temperature control | ||||||
| Volumetric control | 4 programmable doses | 4 programmable doses | 4 programmable doses | 4 programmable doses | 4 programmable doses | 4 programmable doses |
| Extraction timer | ||||||
| Statistics | ||||||
| Programmable pre-infusion | ||||||
| App connectivity (Android) | ||||||
| Dynamic pre-heating | ||||||
| Thermal stability | ±0.5°C | ±0.5°C | ±0.5°C | ±0.5°C | ±0.5°C | ±0.5°C |
| Independent professional coffee groups | ||||||
| Stainless Steel independent Steam Boiler | 8.5 l | 8.5 l | 8.5 l | 8.5 l | 8.5 l | 8.5 l |
| Adjusting the Coffee Temperature | 80 to 110°C in 0.1°C increments | 80 to 110°C in 0.1°C increments | 80 to 110°C in 0.1°C increments | 80 to 110°C in 0.1°C increments | 80 to 110°C in 0.1°C increments | 80 to 110°C in 0.1°C increments |
| Steam temperature adjustment | 110 to 165°C in 1°C increments | 110 to 165°C in 1°C increments | 110 to 165°C in 1°C increments | 110 to 165°C in 1°C increments | 110 to 165°C in 1°C increments | 110 to 165°C in 1°C increments |
| Cool touch steam wand | 2x 12mm, double-walled stainless steel | 2x 12mm, double-walled stainless steel | 2x 12mm stainless steel | 2x 12mm stainless steel | 2x 12mm stainless steel | 2x 12mm stainless steel |
| Separate hot water with solenoid | Anti-splash, 2 doses | Anti-splash, 2 doses | Anti-splash | Anti-splash | ||
| Dual pressure gauge | Coffee/Boiler | Coffee/Boiler | Coffee/Boiler | Coffee/Boiler | Coffee/Boiler | Coffee/Boiler |
| Programmable standby | ||||||
| Isulated coffee groups | ||||||
| Heating element in coffee groups | ||||||
| Insulated steam boiler | ||||||
| Insulated Tubes | ||||||
| Active cup warmer | optional | optional | ||||
| Work area lighting | ||||||
| Adjustable height (+/-30mm) | Chrome-plated, large diameter | Chrome-plated, large diameter | Chrome-plated, large diameter | Chrome-plated, large diameter | ||
| Wooden handles | Walnut | Walnut | Walnut | Walnut | Optional | Optional |
| Steam Joystick | Optional, front joystick | Optional, front joystick | ||||
| Stainless Steel Wire Tray | ||||||
| Illuminated panel | Optional | Optional | ||||
| Housing material | Stainless steel | Stainless steel | Stainless steel | Stainless steel | Stainless steel | Stainless steel |
| Weight | 71 kg | 93 kg | 71 kg | 93 kg | 71 kg | 93 kg |
| Max. cup height | 9 or 12cm | 9 or 12cm | 9 or 12cm | 9 or 12cm | 9 or 12cm | 9 or 12cm |
| Dimensions (W x H x D) | 700 x 475 x 535 mm | 920 x 475 x 535 mm | 700 x 475 x 535 mm | 920 x 475 x 535 mm | 700 x 475 x 535 mm | 920 x 475 x 535 mm |
| Power per coffee group | 1000 W | 1000 W | 1000 W | 1000 W | 1000 W | 1000 W |
| Boiler power | 3500 W | 3500 W | 3500 W | 3500 W | 3500 W | 3500 W |
| Voltage | 380 V (3F) | 220 - 240 V 50/60Hz | 380 V (3F) | 220 - 240 V 50/60Hz | 380 V (3F) | 220 - 240 V 50/60Hz | 380 V (3F) | 220 - 240 V 50/60Hz | 380 V (3F) | 220 - 240 V 50/60Hz | 380 V (3F) | 220 - 240 V 50/60Hz |
| “Power Guard” system | ||||||
| Accessories | ||||||
|---|---|---|---|---|---|---|
| Stainless steel portafilter with a single nozzle | Walnut handle | Walnut handle | Walnut handle | Walnut handle | ||
| Stainless steel portafilter with double nozzle | 2, Walnut handle | 3, Walnut handle | 2, Walnut handle | 3, Walnut handle | 2 | 3 |
| Stainless steel bottomless portafilter | ||||||
| 7 gr stainless steel filter (1 coffee) | 1 competition | 1 competition | 1 | 1 | 1 | 1 |
| 14 gr stainless steel filter (2 coffees) | 2 competition | 3 competition | 2 | 3 | 2 | 3 |
| 18 gr stainless steel filter (2 coffees) | 2 competition | 3 competition | ||||
| 21 gr stainless steel filter (3 coffees) | ||||||
| Blind filter | ||||||
| Filter Holder Gasket | Silicone | Silicone | Silicone | Silicone | Gum | Gum |
| Stainless steel shower | 200 μm, competition shower | 200 μm, competition shower | 200 μm, competition shower | 200 μm, competition shower | Standard | Standard |
| Steam Tip | PEEK, 4 holes | PEEK, 4 holes | 4 holes | 4 holes | 4 holes | 4 holes |
| Tamper | Wood and stainless steel | Wood and stainless steel | Stainless steel | Stainless steel | Aluminium | Aluminium |
