Ideal for shops, offices and accommodations
Bar Mini is the ideal solution for businesses and spaces where coffee is not the center of activity, but a key part of the customer experience. Designed for medium-low workloads, it offers the quality of a consistent espresso with the simplicity, speed and efficiency required by small businesses, offices and tourist accommodations.
More service in less time
Thanks to its two-group configuration and triple Thermoblock, Bar Mini allows you to prepare coffee and steam simultaneously, eliminating downtime and improving daily productivity. Its plug & play, boiler-free system reduces maintenance, minimizes breakdowns and avoids complex installations, which translates into a lower total cost of ownership.
A step beyond the compact segment
Compact, efficient and easy to use, Bar Mini is positioned above the standard of the compact segment, offering thermal stability and sufficient steam for an agile and consistent service. A machine designed for those looking for professional quality, without oversizing investment, space or resources.
Highlights
Thermoblock
High-performance triple Thermoblock
Pid Control
Thermal stability of +/-1.5°C with PID controller
Volumetric control
Volumetric control, Extraction Timer, Programmable Pre-Infusion, and Overpressure Valve
High quality
High-quality materials, accessories and components in stainless steel
Water tank
2 Side removable water tanks
Design
Modern and industrial design
| Sheet | BAR MINI |
|---|---|
 |
|
| Pump | Vibratory |
| PID temperature control | via screen |
| Digital Multifunction Display | 2 |
| Volumetric control | 2 programmable doses |
| Extraction timer | |
| Statistics | |
| Programmable pre-infusion | |
| Separate hot water | |
| Thermal stability | ±1.5°C |
| Independent coffee and steam groups | 3 |
| Adjusting the Coffee Temperature | 80°C to 110°C in 1°C increments |
| Steam temperature adjustment | 110°C to 165°C in 1°C increments |
| Water tank visible from the outside | 2x2L |
| Cool touch steam wand | 10mm stainless steel |
| Manometer | 2 |
| Externally adjustable overpressure valve | |
| Programmable standby | |
| Thermoblock with thermal insulation | |
| Active cup warmer | |
| Housing material | Stainless steel |
| Weight | 21 kg |
| Dimensions (W x H x D) | 480 x 360 x 315 mm |
| Power | 3000 W |
| Voltage | 220V-120V |
| Accessories | |
|---|---|
| BAR MINI | |
| Stainless steel portafilter with double nozzle | |
| Stainless steel bottomless portafilter | |
| 7 gr stainless steel filter (1 coffee) | |
| 14 gr stainless steel filter (2 coffees) | |
| 18 gr stainless steel filter (2 coffees) | |
| 21 gr stainless steel filter (3 coffees) | |
| Blind filter | |
| Filter Holder Gasket | Silicone |
| Stainless steel shower | 200 μm, competition shower |
| Steam Tip | 1 hole and 3 holes |
| Tamper | Stainless steel |
| Spoon | |
| Shower brush |
